Viewline Series Free-Standing Luminaire Low UGR Anti-glare LED floor lamp

Short Description:

Size: 1118 x 46 x 2000mm

Color: Matt White(RAL9016), matt black(RAL9005)

Housing Material: Aluminium

Lens Material: PMMA

Louver reflector Material: PC

Product Detail

Product Tags

Viewline free-standing luminaire4
Viewline free-standing luminaire1
Viewline Free-standing Luminaire
Size 1118x46x2000mm
Color Matt White(RAL9016), matt black(RAL9005)
Housing Material Aluminium
Lens Material PMMA
Louver reflector Material PC
Efficacy  115lm/W
Wattage 65W,81W
Voltage 200-240V
Frequency  50/60Hz
THD <15%
Lumen 7500lm(5000lm↑+2500lm↓) @65W, 9000lm(6000lm↑+3000lm↓) @81W
CCT 3000K, 4000K, 3000K-6500K tunable
CRI >80Ra,>90Ra
UGR <13
Lifespan 50000H(L90, Tc=55°C)
Warranty 5 years
Operating -35~45°C
IP Protection IP20
IK Protection IK02
Viewline free-standing luminaire1


1. UGR<13, glare-free and uniform light.

2. Elegant and modular design.

3. Easy installation and operation.

4. High efficiency up-to 115lm/W.

5. No flickering, visual comfort.

Viewline free-standing luminaire2

Uniform Light

Viewline free-standing luminaire1

Product Details

Viewline free-standing luminaire4
Viewline free-standing luminaire8


Viewline free-standing luminaire7
stehlampe buero_Sundopt

Factory Show

Viewline free-standing luminaire10

Our Advantages:

1. 12 years R&D and manufacturing in LED industry, Solid OEM/ODM partner for Top5 lighting brands in China, Amenca& Europe market, more than 35 engineers in Molding, Optic, Electronic, Mechanical and product application divisions. For better management of raw matenial lead time, Sundopt set up its own die-casting factory in 2017. In 2019. its total revenue is more than 30 million us dollar.

2. Sundopt is founded in year 2008, we are a leading LED commercial general lighting manufacturer of China, with 15000 square meters factory in Shenzhen which includes all kind of test machines for quality control and R&D, 2 automatic production lines for panel lights, we also own one assembly factory in Malaysia which can bypass the extremely high tariff amid US-CHINA trade war.

3. Sundopt's product are designated with the high cost-effective, high performance LED solution for High-end lighting project business, the core marterials used are TOP supplier in LED industry such as Osram, Tridonic, LIFUD drivers, Samsung, Nichia, Epistar leds. Our Clients are located more than 50 countries and they are producing high quality crops and elevated yields by using our lights. Most of our products are 3-5 years warranty.
